Product Description
Targeted Applications and User Profile
This 3.7v lithium ion battery is engineered for industrial users requiring stable, long-lasting power solutions in compact form factors. It supports electronics manufacturers, IoT device developers, and equipment integrators demanding a dependable, high capacity battery to enhance system reliability and operational efficiency. The pouch format allows adaptable sizing to meet bespoke product requirements, providing designers and engineers with a flexible power source that aligns with diverse application needs. lithium ion battery manufacturers and lithium ion battery suppliers benefit from this battery’s compatibility and scalable features for integration across a wide range of high-demand environments.
Technical Features and Specifications
Built to strict international standards, this prismatic lithium battery offers a nominal voltage of 3.7V with a rated capacity of 50Ah. It boasts a minimum cycle life of 1200 cycles, retaining at least 80% capacity, ensuring durability in rigorous applications. The battery supports a maximum continuous discharge current of 2C and a peak of 3C, with an internal resistance below 1.5mΩ, delivering consistent, stable output. Certifications including CE, RoHS, UN38.3, IEC62133, and MSDS validate its compliance with global safety regulations. The lightweight pouch design enhances thermal management and facilitates integration into customized assemblies for optimized battery system designs typical among lithium ion battery manufacturers.
Industry Applications and Operational Value
This high capacity battery supports critical functions in sectors such as smart security systems, portable medical instruments, and connected consumer electronics. Its reliable charge-discharge cycling ensures uninterrupted performance in demanding environments, making it an essential component for IoT devices and wearable technology where endurance and safety are paramount. Lithium ion battery suppliers can leverage this battery’s proven reliability and certification portfolio to supply advanced battery solutions with a demonstrated ability to maintain capacity over extended use, thus delivering long-term value and minimizing operational downtime in industrial and commercial deployments.
| Item |
Specifications |
Remark |
| Model No. |
LP88165265 |
|
| Nominal Voltage |
3.7V |
|
| Nominal Capacity |
50Ah |
Standard discharge after standard charge |
| Dimensions |
8.8x165x265mm |
ThicknessxWidthxLength |
| Cycle Life |
≥1200 times |
≥ 80% of the initial capacity |
| Charge Method |
1C CC to 4.2V, 4.2V CV to 0.05C |
Use a dedicated lithium battery charger |
| Charge Cut-off Voltage |
4.2V |
|
| Discharge Cut-off Voltage |
2.75V |
|
| Standard Charge Current |
0.33C |
|
| Standard Discharge Current |
0.5C |
|
| Max Continuous Charge Current |
1C |
|
| Max Continuous Discharge Current |
2C |
|
| Max Peak Discharge Current |
3C |
|
| Recommended Operation Ambient Temperature |
Charge: 0~45℃ Discharge:-20~60℃ |
|
| Storage Temperature |
-20℃~25℃ |
12 months |
| -20℃~35℃ |
3 months |
| -20℃~45 ℃ |
1 month |
| Internal Resistance |
≤1.5mΩ |
|
| Weight |
Approx. 816g |
|
-High safety
-Real capacity
-Flexible size, lightweight, customizable
-Cycle life above 800 times
-Factory direct price, High quality with certifications
-Above 20 years manufacturing experience
Bluetooth speaker, bluetooth headset, smart home controller, smart security device, intelligent door lock, smart glass, gps tracker, parking device, medical device, POS machine, wearable device, IoT device, sensor, handheld device, alarm system, beauty device, etc.
Safety certificate: CE,CB, IEC62133, UL, PSE
Environmental certificate: ROHS, REACH
Quality management certificate: ISO9001, ISO14001, BSCI
Shipping certificate: UN38.3, MSDS, Air/Sea Transport Identification&Classification Report
01 Materials Mixing
Fully automatic feeding system,High precision, fully enclosed
02 Coating
High precision constant temperature coating machine
03 Electrode Piece Rolling
Precision automatic roller machine
04 Electrode Piece Slitting
Automatic battery electrode piece continuous slitting machine
08 High Temperature Baking
75-80 ℃ vacuum constant temp baking for more than 36 hours
07 Cell Sealing
High temp top&side sealing machine with good side sealing effect
06 Automatic Winding
Make the widing core consistent, save manpower and high efficiency
05 Automatic Electrode Piece Making
Ultrasonic spot welding, firm welding and low internal resistance
09 Automatic Injection
Effectively isolate moisture
10 Formation
Constant fomration cabinet, activate the battery
11 Capacity Sorting
All cells will be 100% tested for 3 cycles.
12 OQC Test
100% full test on appreance, voltage, capacity, resistance, size, etc
With 20 years experience in battery field, Topwell can arrange the battery ship by Sea / Air / Express.
We can provide you with all DG certification which allows you to ship these batteries,
such as UN38.3 /MSDS /DG. We can ship from Shenzhen,Shanghai,HK...
FAQ
What customization options are available for the 3.7V 50Ah Pouch Lithium Polymer Battery?
We offer flexible sizing and capacity customization due to the pouch design, allowing the battery to meet specific application requirements. As a reliable lithium ion battery manufacturer, we tailor solutions to your industrial needs for optimal integration and performance.
How do you ensure the safety and quality of your lithium ion batteries?
Our lithium ion batteries comply with strict certifications such as CE, RoHS, UN38.3, IEC62133, and MSDS. We apply rigorous testing and quality control processes to deliver safe, reliable products suitable for varied industrial applications.
What is the recommended charging method for this high capacity battery?
We recommend charging at 1C constant current to 4.2V, followed by 4.2V constant voltage until the current drops to 0.05C using a dedicated lithium battery charger. Proper charging maintains performance and longevity for this high capacity battery.
Can you support logistics and delivery timelines for bulk orders?
We typically deliver samples within 2 weeks and mass production orders within 4-5 weeks, depending on quantity and customization. Our extensive experience as a lithium ion battery supplier helps ensure reliable and timely fulfillment globally.
