| Item |
Specifications |
Remark |
| Model No. |
LF14500-600 |
|
| Nominal Voltage |
3.2V |
|
| Nominal Capacity |
600mAh |
@0.2C discharge |
| Dimensions |
14.2*50.5mm max |
Diameter*Height |
| Cycle Life |
≥2000 times |
≥ 80% of the nominal capacity |
| Charge Method |
CC/CV |
lithium battery special charger |
| Charge Cut-off Voltage |
3.65V |
|
| Discharge Cut-off Voltage |
2.3V |
|
| Standard Charge Current |
0.2C |
|
| Standard Discharge Current |
0.2C |
|
| Max Continuous Charge Current |
1C |
|
| Continuous Discharge Current |
1C |
|
| Peak Discharge Current |
3C |
|
| Recommended Operation Ambient Temperature |
Charge: 0~45℃ Discharge:-20~60℃ |
|
| Storage Temperature |
-20℃~25℃ |
12 months |
| -20℃~35℃ |
3 months |
| -20℃~45 ℃ |
1 month |
| Internal Resistance |
≤50mΩ |
|
| Weight |
Approx. 16g |
|
-High safety
-Green and Environmental
-High discharge rate, Low internal resistance
-Good at high temperature and low temperature environment
-High consistency in capacity&voltage&resistance
-Long cycle life over 2000 times, 8-10 years use life
Solar energy storage system, home energy storage, outdoor power supply, solar street light, lawn lamp, miner's lamp, emergency light, backup power, UPS, communication base station, EV, electric scooter, electric bike, electric motorbike, electric tricycle, golf cart, RV, power tool, garden tool, power bank, small home appliances, etc.
Safety certificate: CE,CB, IEC62133, UL, PSE
Environmental certificate: ROHS, REACH
Quality management certificate: ISO9001, ISO14001, BSCI
Shipping certificate: UN38.3, MSDS, Air/Sea Transport Identification&Classification Report
01 Materials Mixing
Fully automatic feeding system,High precision, fully enclosed
02 Coating
High precision constant temperature coating machine
03 Electrode Piece Rolling
Precision automatic roller machine
04 Electrode Piece Slitting
Automatic battery electrode piece continuous slitting machine
08 Injection
Fully automatic bell type liquid injection machine
07 Tab Welding&Beading
Automatic welding machine
05 Winding
Automatic winding machine
09 Automatic Laser Welding
10 Formation&Capacity Sorting
Needle bed type charging cabinet
11 Cycle Test
All cells will be 100% tested for 3 cycles.
12 OQC Test
100% full test on appreance, voltage, capacity, resistance, size, etc
With 20 years experience in battery field, Topwell can ship the battery by Sea / Air / Express.
We can provide you with all DG certification which allows you to ship these batteries, such
as UN38.3 /MSDS /DG. We can ship from Shenzhen,Shanghai,HK...
