Product Description
Targeted Energy Solution for UAV and Drone Professionals
This advanced 3.65V 35Ah semi-solid-state lithium polymer battery is engineered to meet the rigorous power requirements of UAV operators and FPV drone developers. Designed by a leading lithium ion battery supplier, it serves users requiring a robust, lightweight, and efficient energy source. The battery’s nominal voltage and high-capacity configuration allow for prolonged flight times and stable performance critical to professional drone operations and experimental platforms that demand precise discharge and recharge cycles.
Technical Specifications Emphasizing Performance and Durability
Integrating latest semi-solid-state lithium polymer technology, this battery achieves an internal resistance of ≤1.4mΩ, supporting continuous discharge currents up to 3C with peaks at 5C for responsive power delivery. Certified by CE, RoHS, UN38.3, and IEC62133 standards, it ensures compliance with international safety protocols. With over 800 charge-discharge cycles at controlled temperatures, its durability meets the lifespan expectations of engineers requiring dependable, repeatable performance in demanding conditions while maintaining a compact profile that assists system integration efforts.
Application Versatility Across Aerospace and Remote Systems
Deployed extensively in UAV and FPV drone applications, this battery powers critical subsystems such as communication arrays, onboard sensors, and high-definition cameras. Its high capacity battery attributes enable extended mission endurance and reliable backup power in remote environments. This power source is also adaptable in remote-controlled aircraft and custom drone designs where footprint constraints and energy density are pivotal. By partnering with a reputable lithium ion battery manufacturer, system integrators gain enhanced operational reliability and improved return on investment.
| Item |
Specifications |
Remark |
| Model No. |
LP1187187 |
|
| Nominal Voltage |
3.65V |
|
| Nominal Capacity |
35Ah |
Standard discharge after standard charge |
| Dimensions |
11x87x187mm |
ThicknessxWidthxLength |
| Cycle Life |
≥800 cycles |
25℃±2℃,0.5C/3C,97%DOD |
| Charge Method |
0.33C CC to 4.2V, 4.2V CV to 0.05C |
|
| Charge Cut-off Voltage |
4.2V |
|
| Discharge Cut-off Voltage |
2.75V |
|
| Standard Charge Current |
0.33C |
|
| Standard Discharge Current |
0.33C |
|
| Max Continuous Charge Current |
2C |
|
| Max Continuous Discharge Current |
3C |
|
| Max Peak Discharge Current |
5C |
|
| Recommended Operation Ambient Temperature |
Charge: 0~45℃ Discharge:-20~60℃ |
|
| Storage Temperature |
-10℃~35℃ |
6 months |
| -20℃~45 ℃ |
1 month |
| Internal Resistance |
≤1.4mΩ |
|
| Weight |
Approx. 410g |
|
-High safety
-Real capacity
-Flexible size, lightweight, customizable
-Cycle life above 800 times
-Factory direct price, High quality with certifications
-Above 20 years manufacturing experience
Bluetooth speaker, bluetooth headset, smart home controller, smart security device, intelligent door lock, smart glass, gps tracker, parking device, medical device, POS machine, wearable device, IoT device, sensor, handheld device, alarm system, beauty device, etc.
Safety certificate: CE,CB, IEC62133, UL, PSE
Environmental certificate: ROHS, REACH
Quality management certificate: ISO9001, ISO14001, BSCI
Shipping certificate: UN38.3, MSDS, Air/Sea Transport Identification&Classification Report
01 Materials Mixing
Fully automatic feeding system,High precision, fully enclosed
02 Coating
High precision constant temperature coating machine
03 Electrode Piece Rolling
Precision automatic roller machine
04 Electrode Piece Slitting
Automatic battery electrode piece continuous slitting machine
08 High Temperature Baking
75-80 ℃ vacuum constant temp baking for more than 36 hours
07 Cell Sealing
High temp top&side sealing machine with good side sealing effect
06 Automatic Winding
Make the widing core consistent, save manpower and high efficiency
05 Automatic Electrode Piece Making
Ultrasonic spot welding, firm welding and low internal resistance
09 Automatic Injection
Effectively isolate moisture
10 Formation
Constant fomration cabinet, activate the battery
11 Capacity Sorting
All cells will be 100% tested for 3 cycles.
12 OQC Test
100% full test on appreance, voltage, capacity, resistance, size, etc
With 20 years experience in battery field, Topwell can arrange the battery ship by Sea / Air / Express.
We can provide you with all DG certification which allows you to ship these batteries,
such as UN38.3 /MSDS /DG. We can ship from Shenzhen,Shanghai,HK...
FAQ
What certifications ensure the safety and quality of your lithium ion batteries?
We hold certifications including CE, RoHS, UN38.3, IEC62133, and MSDS to guarantee our batteries meet high safety and quality standards. These certifications confirm compliance with international regulations, ensuring our lithium ion battery supplier products are reliable for UAV and FPV drone applications.
Can you customize the 3.65V 35Ah battery for specific industrial needs?
Yes, as an experienced lithium ion battery manufacturer, we offer customization services to fit your project requirements. Whether you need tailored dimensions, capacity, or discharge rates, our engineering team can develop a solution based on your application specifications.
How should I maintain the battery to achieve its rated 800+ cycle life?
To maximize cycle life, operate the battery within recommended temperatures (charge 0~45℃, discharge -20~60℃) and follow charging parameters precisely. Proper storage at -10℃~35℃ for up to 6 months also helps maintain performance. Our technical support can provide detailed maintenance guidance.
What logistics and shipping standards do you comply with for drone battery delivery?
We ensure all shipments comply with UN38.3 and MSDS regulations for air and sea transport, enabling safe and legal delivery worldwide. You can trust us as a reliable lithium ion battery supplier for compliant logistics and secure packaging tailored to your shipment needs.
